Feature Selection

Grayson White

Stat 243
Week 5 | Fall 2026

Math / Stats / CS Hike!!!

This year’s annual Math/Stats/CS picnic-hike will take place on Saturday, October 10th, from approximately 9:00am (leave Reed) until approximately 2:00pm (return to Reed). The location of the hike is Tryon Creek State Natural Area (approx 7.5 miles from Reed).

A boxed lunch will be provided. Hiking trails are available but don’t feel like you have to hike - there will be games and other activities available at the picnic tables.

Please use this link to sign-up and order a lunch which the departments will cover.

Deadline to sign up is Thursday at Noon - 10/01.

Goals for today (and next time)

Today:

Investigate algorithms for selecting good subsets of predictors
Discuss new metrics for model selection (beyond \(R^2\) and adj \(R^2\)!)
Discuss ways to create and modify predictors

Next time:

Quiz
Proof of MSE = Bias\(^2\) + Var

Subset Selection

Methodology

Suppose we wish to find a linear model for \(Y\) with \(p\) predictors \(X_1, \dots, X_p\). How do we determine the optimal collection of predictors?

First, determine an appropriate selection procedure:

Cross-validation: Computationally expensive, but also most accurate; requires no model or data assumptions; best overall
Validation set: Subject to variability in test/training split; but can be alright for large data sets, or initial exploration
Training set assessment: using RSS alone on training will lead to overfitting and biased estimate of test MSE;
- Instead, can apply penalty to RSS based on number of predictors in the model, in order to better estimate test MSE
- However, can use if validation set is not available, or if large number of models need to be considered.

Training Set Criteria

To compare models on the training set, we can use the following metrics, each of which penalizes the training RSS. Suppose we have \(d\) predictors in the model and \(n\) observations:

Adjusted \(R^2\). Best models have largest \(\textrm{adj }R^2\)

\[ \textrm{adj }R^2 = 1 - \frac{\textrm{RSS}/(n-d-1)}{\textrm{TSS}/(n-1)} \]

\(C_p\). Best models have smallest \(C_p\)

\[ C_p = \frac{1}{n}(\mathrm{RSS} + 2 d \hat{\sigma}^2) \]

Akaike information criterion (AIC). Best models have smallest \(\textrm{AIC}\)

\[ \mathrm{AIC} = \frac{1}{n \hat{\sigma}^2}(\mathrm{RSS} + 2 d \hat{\sigma}^2) \]

Bayesian information criterion (BIC). Best models have smallest \(\textrm{BIC}\)

\[ \mathrm{BIC} = \frac{1}{n \hat{\sigma}^2}(\mathrm{RSS} + \log(n) d \hat{\sigma}^2) \]

Here, \(\hat\sigma^2\) is the estimated from the full model that contains all predictors.

Comparison of Formulas

Criteria Formulas:

\(C_p = \frac{1}{n}(\mathrm{RSS} + 2 d \hat{\sigma}^2)\)	\(\textrm{adj }R^2 = 1 - \frac{\textrm{RSS}/(n-d-1)}{\textrm{TSS}/(n-1)}\)
\(\mathrm{AIC} = \frac{1}{n \hat{\sigma}^2}(\mathrm{RSS} + 2 d \hat{\sigma}^2)\)	\(\mathrm{BIC} = \frac{1}{n \hat{\sigma}^2}(\mathrm{RSS} + \log (n) d \hat{\sigma}^2)\)

When \(n\) is large relative to \(d\), \(R^2 \approx \textrm{adj }R^2\). Since \(R^2\) overfits models, \(\textrm{adj }R^2\) will also tend to overfit, and so shouldn’t be used.
Other than a multiplicative constant (that doesn’t depend on the model), \(C_p\) and \(\textrm{AIC}\) are equal, and so will always preference the same models
Both \(\textrm{AIC}\) and \(\textrm{BIC}\) apply a penalty for adding additional predictors; since \(\log(n) > 2\), this penalty is greater for \(\textrm{BIC}\) than \(\textrm{AIC}\); hence, BIC will select models with fewer variables.
When comparing models with the same number of variables, differences in these criteria values will only depend on differences in RSS.
- Hence, for fixed number of variables, we can choose the model that has the smallest RSS.

New data context: molecular solubility

The solubility data set from the AppliedPredictiveModeling package contains solubility and chemical structure for a sample of 1,267 different compounds.

library(AppliedPredictiveModeling)
data(solubility)

The solubility of a compound indicates how easily it dissolves in a solvent (often water), and is measured as the amount of solvent required to dissolve 1 part of the compound.
- The less solvent required, the more soluble the compound.
- In the dataset, the log solubility is reported, since solubility spans many orders of magnitude
The data also contains 16 chemical count descriptors, such as “number of bonds” or “number of bromine atoms”
Finally, the data contains 4 continuous descriptors, such as “molecular weight” or “surface area”

We are interested in determining solubility based on these 20 chemical descriptors.

Data preprocessing

library(AppliedPredictiveModeling)
data(solubility)
solTest <- cbind(solTestX, Solubility = solTestY)
solTrain <- cbind(solTrainX, Solubility = solTrainY)
solTest <- solTest %>% select(!starts_with("FP"))
solTrain <- solTrain %>% select(!starts_with("FP"))
head(solTrain)

    MolWeight NumAtoms NumNonHAtoms NumBonds NumNonHBonds NumMultBonds
661    208.28       28           16       30           18           16
662    365.54       49           26       52           29           13
663    206.31       33           15       33           15            7
665    136.26       26           10       26           10            2
668    229.75       31           15       31           15            6
669    270.25       32           15       31           14            2
    NumRotBonds NumDblBonds NumAromaticBonds NumHydrogen NumCarbon NumNitrogen
661           0           0               16          12        14           2
662           4           0               12          23        21           3
663           4           1                6          18        13           0
665           1           2                0          16        10           0
668           5           0                6          16         9           5
669           5           2                0          17        10           1
    NumOxygen NumSulfer NumChlorine NumHalogen NumRings HydrophilicFactor
661         0         0           0          0        3            -0.856
662         1         1           0          0        4            -0.370
663         2         0           0          0        1            -0.330
665         0         0           0          0        1            -0.960
668         0         0           1          1        1            -0.069
669         1         1           2          2        0            -0.651
    SurfaceArea1 SurfaceArea2 Solubility
661        25.78        25.78      -3.97
662        52.19        80.43      -3.98
663        37.30        37.30      -3.99
665         0.00         0.00      -4.00
668        53.94        53.94      -4.06
669        20.31        45.61      -4.08

Best Subset

With \(p\) predictors, there are a total of \(2^p\) possible MLR models.

There are \(\binom{p}{d} = \frac{p!}{d!(p-d)!}\) models using exactly \(d\) of \(p\) predictors

Theoretically, we can find the best model by fitting each possible model and selecting the best via appropriate selection criteria.

Downsides?

Computation time and storage grows exponentially in \(p\)
Might not be worth it! May have low marginal improvement despite number of models fitted

Best Subset in R

We use the regsubsets function in the leaps library.

regsubsets uses the same syntax as lm. The summary function outputs the best set of variables for the given number of predictors, across the range supplied
Be default, regsubsets only returns up to the best eight models. But nvmax can be used to return as many variables as desired
The best model for each fixed number of predictors is determined by \(RSS\)
The regsubsets function returns \(RSS\), \(\textrm{adj}R^2\), \(C_p\), and \(BIC\) for the best model of each number of predictors.
The overall best model can be selected using any of these criteria.

Using `regsubsets`

library(leaps)
best_subset <- regsubsets(Solubility ~ . -NumNonHBonds -NumHydrogen -NumRings,
                        data = solTrain,
                        nvmax = 17)

The regsubsets function itself outputs a special regsubsets object, which contains data but is not user-accessible.

We’ll use the summary function, which provides the following elements:
- which: a list of which predictors are in each model
- outmat: a version of which for printing
- Several metrics: rsq, rss, adjr2, cp, bic

Summary of `regsubsets`

Stars indicate variable is included in model.
For readability, I’ve only shown models with 5 or fewer variables

best_subset5 <- regsubsets(Solubility ~ . -NumNonHBonds -NumHydrogen -NumRings,
                           data = solTrain,
                           nvmax = 5)
summary(best_subset5)$outmat

         MolWeight NumAtoms NumNonHAtoms NumBonds NumMultBonds NumRotBonds
1  ( 1 ) "*"       " "      " "          " "      " "          " "
2  ( 1 ) "*"       " "      " "          " "      " "          " "
3  ( 1 ) "*"       " "      " "          " "      "*"          " "
4  ( 1 ) " "       " "      "*"          " "      " "          " "
5  ( 1 ) " "       " "      "*"          "*"      " "          "*"
         NumDblBonds NumAromaticBonds NumCarbon NumNitrogen NumOxygen NumSulfer
1  ( 1 ) " "         " "              " "       " "         " "       " "
2  ( 1 ) " "         " "              " "       " "         " "       " "
3  ( 1 ) " "         " "              " "       " "         " "       " "
4  ( 1 ) " "         " "              "*"       "*"         "*"       " "
5  ( 1 ) " "         " "              " "       "*"         "*"       " "
         NumChlorine NumHalogen HydrophilicFactor SurfaceArea1 SurfaceArea2
1  ( 1 ) " "         " "        " "               " "          " "
2  ( 1 ) " "         " "        " "               "*"          " "
3  ( 1 ) " "         " "        " "               "*"          " "
4  ( 1 ) " "         " "        " "               " "          " "
5  ( 1 ) " "         " "        " "               " "          " "

Other Selection Metrics

The summary function can return selection metrics for each model.

d <- tibble(
  model = 1:17,
  adjr2 = summary(best_subset)$adjr2,
  rss = summary(best_subset)$rss,
  cp = summary(best_subset)$cp,
  bic = summary(best_subset)$bic
)
d

# A tibble: 17 × 5
   model adjr2   rss     cp    bic
   <int> <dbl> <dbl>  <dbl>  <dbl>
 1     1 0.395 2404. 1992.   -466.
 2     2 0.659 1354.  710.  -1005.
 3     3 0.712 1142.  453.  -1160.
 4     4 0.745 1012.  296.  -1268.
 5     5 0.774  894.  154.  -1379.
 6     6 0.781  865.  120.  -1404.
 7     7 0.787  840.   91.8 -1425.
 8     8 0.796  805.   50.8 -1458.
 9     9 0.799  793.   38.1 -1466.
10    10 0.800  789.   35.4 -1464.
11    11 0.801  783.   30.8 -1463.
12    12 0.802  779.   27.1 -1462.
13    13 0.803  774.   23.3 -1461.
14    14 0.804  769.   19.2 -1460.
15    15 0.805  764.   15.0 -1460.
16    16 0.805  763.   16.4 -1454.
17    17 0.805  763.   18   -1447.
